ROCKWELL 75A “SABRE”€

1963’€“83

Gemini Sparkle

Key Takeaways:

  • The North American Sabreliner, an executive jet, originated in 1958 as a military utility transport (T-39) before its commercial launch in 1963.
  • Its military design background contributes to its rugged, powerful, and larger medium-sized frame, offering excellent climb performance and a 45,000-foot ceiling.
  • Despite its power, its cruise speed is considered modest by jet standards.
  • Models like the Sabreliner 74 and Sabre 60 were equipped with thrust reversers to facilitate shorter landings and assist on challenging runways.
See a mistake? Contact us.
iad
STANDARD DATA: Seats 10. Gross wt. 23,000. Empty wt. 13,000. Fuel capacity 1,102. Engines two 4,315-lb. s.t. General Electric turbofans.
PERFORMANCE: Top mph 563. Cruise mph 527. Stall mph 99. Initial climb rate 4,500. Range 1,938. Ceiling 45,000. Takeoff run (balanced) 4,900. Landing roll 2,525.

As the North American Sabreliner, this executive jet bore a famous name. It actually began as a military utility transport aircraft and dates back to 1958. The commercial version emerged in 1963 as the Sabreliner. In its civilian form as an airliner and business jet, the Sabreliner ranks as medium sized. Its speed by jet standards is modest with a cruise of 489 knots. Because the Sabreliner was originally designed as a military T-39 and was designed to meet military specifications, it shows unmistakable signs of its origin. It is larger and more rugged and powerful than jets that have been designed solely for civilian use. The Sabreliner has excellent climb performance and a ceiling of 45,000 feet. Rockwell also built a Sabre 60 jet equipped with 3,300-lb.-thrust engines. Both the 74 and 60 models were fitted with thrust reversers to aid in shorter landings and assist in braking on icy or wet runways.
