Cessna TTx Specifications

Cessna TTx
Gemini Sparkle

Key Takeaways:

  • The article describes a loaded late 2016 Textron Aviation Cessna TTx, equipped with advanced Garmin G3000 avionics, a GFC700 autopilot, and safety features like envelope protection and a TKS anti-ice system.
  • Constructed from composite materials, this 4-seat aircraft is powered by a 310 HP Continental TSIO-550-C engine.
  • It demonstrates strong performance capabilities, including a top cruise speed of 235 knots, a maximum operating altitude of 25,000 feet, and a maximum range of 1,270 nautical miles.
  • The reviewed model had a price of $810,785, with a base price of $689,000.
See a mistake? Contact us.

The Textron Aviation Cessna TTx we flew for this report was a loaded late 2016 model with the standard Garmin G2000 touch-controlled avionics suite, with the GFC700 digital autopilot, SiriusXM aviation weather and entertainment, envelope protection, terrain and traffic awareness utilities, flight into known icing TKS anti-ice system, and more.


Price As Flown:$810,785

Base Price: $689,000

Main Construction: Composite

Engine: Continental TSIO-550-C

Horsepower: 310

Propeller: McCauley 3-blade, constant speed, metal, 78″ diameter

Avionics: Garmin G3000

Landing gear: Fixed

Seats: 4

Doors: 2

Empty weight: 2,530 lbs.

Payload: 458 lbs. (full fuel)

Useful Load: 1,070 lbs.

Maximum Takeoff Weight: 3,600 lbs.

Fuel Capacity: 102 gal usable/612 lbs.

Wingspan: 36 ft.

Length: 25.2 ft.

Height: 9 ft.

Cabin Width: 48 in.

Maximum Climb Rate: 1,400 fpm

TopCruise Speed: 235 kts

Stall, Landing Configuration: 60 kts

Maximum Operating Altitude: 25,000 ft.

Maximum Range: 1,270 nm

Takeoff Distance: 1,280 ft. (ground roll)

Landing Distance: 1,260 ft. (ground roll)

Read our Cessna TTx pilot report


Check out the TTx and other fantastic single-engine airplanes in our latest Piston Singles Buyer’s Guide.
