Main Construction: Steel tubular frame with fabric, metal wings
Engine/HP: Lycoming O-540-B4B5/235 hp
Propeller: Hartzell or McCauley, 2- or 3-blade, metal, constant speed, 78″- 81″ diameter
Avionics: Analog Six-pack, JPI EDM-930
Top Cruise Speed: 137 kts
Stall, Landing Configuration: 35 kts
Max Range: 800 nm (30-minute reserve)
Max Takeoff Weight: 2,500 lbs.
Payload (full fuel): 385 lbs.
Useful Load: 895 lbs.
Takeoff/Landing Distance: 600 ft./900 ft. (50 ft. Obstacle)
