2017 Piper Archer DX

Specifications

Piper Archer DX
Gemini Sparkle

Key Takeaways:

  • The aircraft has a base price of $412,645 and features metal main construction.
  • It is powered by a 155 hp Continental CD-155 engine, utilizes an MT 3-blade composite propeller, and is equipped with Garmin G1000 avionics.
  • Key performance figures include a top cruise speed of 123 kts and a maximum range of 848 nm.
  • Operational specifications show a max takeoff weight of 2,550 lbs and a payload of 488 lbs with full fuel.
See a mistake? Contact us.

Base Price: $412,645

Main Construction: Metal

Engine/HP: Continental CD-155/155 hp

Propeller: MT, 3-blade, composite, constant speed, 71″ diameter

Avionics: Garmin G1000

Top Cruise Speed: 123 kts

Stall, Landing Configuration: 49 kts

Max Range: 848 nm (45-minute reserve)

Max Takeoff Weight: 2,550 lbs.

Payload (full fuel): 488 lbs.

Useful Load: 794 lbs.

Takeoff/Landing Distance: 1,673 ft./1,400 ft. (50 ft. Obstacle)
