2004 Diamond DA40 Star N59GA

Plane & Pilot

Saturday, May 01, 2004 at 12:00 AM ET

Verified

Edited By: Omar Filipović

Key Takeaways:

The article presents detailed technical specifications for the 2004 Diamond DA40 Star N59GA aircraft.
It is a 4-seat aircraft powered by a 180 hp Lycoming IO-360-MIA engine and features fixed tricycle landing gear.
Key specifications include a base price of $224,900 for the G1000 model, a useful load of 894 lbs, and a usable fuel capacity of 39 gallons.

See a mistake? Contact us.

2004 Diamond DA40 Star N59GA

Base price (G1000 model):

$224,900

Engine make/model:

Lycoming IO-360-MIA

Horsepower@rpm@takeoff:

180@SL

Horsepower for takeoff:

180

TBO hrs.:

2000

Fuel type:

100/100LL

Propeller type/diameter (in.):

MT CS/71

Landing gear type:

Tri/Fixed

Max ramp weight (lbs.):

2535

Gross weight (lbs.):

2535

Landing weight (lbs.):

2535

Empty weight, std. (lbs.):

1641

Useful load (lbs.):

894

Payload, full std. fuel (lbs.):

660

Usable fuel, std. (gals.):

Oil capacity (qts.):

Wingspan:

39 ft. 5 in.

Overall length:

26 ft. 4 in.

Height:

6 ft. 6 in.

Wing area (sq. ft.):

145

Wing loading (lbs./sq. ft.):

17.4

Power loading (lbs./hp.):

Wheel size (in.):

6.00 x 6

Seating capacity:

Cabin doors:

Cabin width (in.):

Cabin height (in.):

Source: Aircraft Bluebook Price Digest, Jane’s All The World’s Aircraft, manufacturer’s specs
